Carefully selected materials
Strictly use raw materials for production refuse to cut corners
Mature technology
Years ofindustry production experience mature technology
Strict quality inspection
Strictly control each procedure and strictly test the products
Support customization
Factory processing and manufacturing can be customized according to your reasonable needs
| Stock No. Color | WLL | SWL,WLL(t),M,CC | Double Multi-set SWL(t) | |||||||
| Vertical | Choker | Vertical | Choker | Vertical | Choker | Vertical | ||||
| 0-7° | 7-45° | 45-60° | <45° | <45° | 45-60° | 45-60° | ||||
| 1 | 0.8 | 2 | 1.4 | 1 | 1.4 | 1.12 | 1 | 0.8 | ||
| HY7010 | 1t | 1,000 | 800 | 2,000 | 1,400 | 1,000 | 2,800 | 1,120 | 1,000 | 800 |
| HY7020 | 2t | 2,000 | 1,600 | 4,000 | 2,800 | 2,000 | 5,600 | 2,240 | 2,000 | 1,600 |
| HY7030 | 3t | 3,000 | 2,400 | 6,000 | 4,200 | 3,000 | 8,400 | 3,360 | 3,000 | 2,400 |
| HY7040 | 4t | 4,000 | 3,200 | 8,000 | 5,600 | 4,000 | 11,200 | 4,480 | 4,000 | 3,200 |
| HY7050 | 5t | 5,000 | 4,000 | 10,000 | 7,000 | 5,000 | 14,000 | 5,600 | 5,000 | 4,000 |
| HY7060 | 6t | 6,000 | 4,800 | 12,000 | 8,400 | 6,000 | 16,800 | 6,720 | 6,000 | 4,800 |
| HY7080 | 8t | 8,000 | 6,400 | 16,000 | 11,200 | 8,000 | 22,400 | 8,960 | 8,000 | 6,400 |
| HY7100 | 10t | 10,000 | 8,000 | 20,000 | 14,000 | 10,000 | 28,000 | 11,200 | 10,000 | 8,000 |
| HY7120 | 12t | 12,000 | 9,600 | 24,000 | 16,800 | 12,000 | 33,600 | 13,440 | 12,000 | 9,600 |
| HY7150 | 15t | 15,000 | 12,000 | 30,000 | 21,000 | 15,000 | 21,000 | 16,800 | 15,000 | 12,000 |
| HY7200 | 20t | 20,000 | 16,000 | 40,000 | 28,000 | 20,000 | 28,000 | 22,400 | 20,000 | 16,000 |
| HY7300 | 30t | 30,000 | 24,000 | 60,000 | 42,000 | 30,000 | 42,000 | 33,600 | 30,000 | 24,000 |
Detailed Photos
Product Description
*Material:100% High tenacity industrial polyester yarn
*Inner core:Made of 60000D twisted polyester yarn
*Double ply outer sleeve,extremely wear-resistant
*Color:Violet
*Working Load:1000kg
*Safety Factor:8:1,7:1,6:1,5;1
*Length Available:1m to 12m
*Low elongation
*According to EN1492- 2+A1:2008
*CE certified
