After Sales Service: Yes
Warranty: yes
Custom: Not Custom
Design: Coaxial
Cutting material: copper, carbon steel, iron, aluminum
Automatic Grade: Automatic, Manual
●
Marca de círculo transparente, firmemente fijada, para no explotar el cilindro.
●
The joint adopts ZG3/8" threaded quick connector, thread lock compact structure
●
Work Lift, Non-Seize Cylinder, Full Tonnage, Full Stroke
China Honyuan Machinery Co., Limited has evolved into a full-service supplier in the distribution of lifting products, material and handling tools, chains, rigging hardware, lifting slings, and wire ropes to meet the needs of our customers. clients in the oil and gas, crane and rigging sectors. , cable installation, stowage, maritime and construction industries in general. In addition, we also deal in fastener China Honyuan Machinery Co., Limited has evolved into a full-service supplier in distributing is and other construction products to meet the requirements of our customers in this line.
Model | YH-16 | YH -20 | YH -22 | YH -25 | YH -32 |
Voltage | AC220V | AC220V | AC220V | AC220V | AC220V |
Frequency | 50Hz | 50Hz | 50Hz | 50Hz | 50Hz |
Wattage | 850/900w | 950/1350w | 1000/1250w | 1600/1700w | 2900/3000w |
Max.rebar diameter | 16mm | 20mm | 22mm | 25mm | 32mm |
Min.rebar diameter | 4mm | 4mm | 4mm | 4mm | 6mm |
Cutting speed | 2.5-3s | 3.0-3.5s | 3.5-4.5s | 3.5-4.5s | 5s |
Machine dimension(mm) | 460*130*115 | 410*115*220 | 420*125*230 | 480*150*255 | 520*170*270 |
Carton dimension(mm) | 515*225*160 | 480*195*285 | 485*190*330 | 565*230*245 | 630*320*260 |
Net weight | 8kg | 13kg | 15kg | 24.5kg | 35kg |
Gross weight | 13kg | 20kg | 21.5kg | 32kg | 43kg |
